✅ Specifications
Platform: Intel
Chipset: Z790
Socket: LGA1700
CPU Support: 14th Gen / 13th Gen / 12th Gen Intel Core, Pentium Gold, Celeron
Form Factor: ATX
Memory Type: DDR5
Memory Channels: Dual Channel
Max Memory Support: 128GB
Max Memory Speed: Up to 7200+
Memory Features: Intel XMP, OptiMem II, Un-buffered Memory
Graphics Output:
HDMI
DisplayPort
Expansion Slots:
1 × PCIe 5.0 x16 (CPU)
3 × PCIe 4.0 x16 (x4 mode)
1 × PCIe 3.0 x1
Storage Support:
3 × M.2 (Key M)
4 × SATA 6Gb/s
LAN: Realtek 2.5Gb Ethernet
Back Panel I/O:
USB 3.2 Gen 2x2 Type-C
USB 3.2 Gen 2 Type-A
USB 3.2 Gen 1 Type-A
USB 2.0
HDMI
DisplayPort
PS/2 Combo Port
Audio Jacks
Vertical M.2 (Key-E) Slot
Internal Connectors:
24-pin ATX Power Connector
8-pin + 4-pin CPU Power Connectors
CPU Fan Header
CPU OPT Fan Header
AIO Pump Header
Chassis Fan Headers
USB Type-C Header
USB 3.2 Gen 1 Headers
USB 2.0 Headers
RGB & ARGB Headers
Thunderbolt (USB4) Header
Front Panel & Audio Headers
COM Port Header
TPM Header
Clear CMOS Header
Warranty: 3 Years
