✅ Specifications
Platform: AMD
Socket: AM5
CPU Support: Ryzen 7000 / 8000 / 9000 Series
Chipset: X870E
Form Factor: ATX
Memory Type: DDR5
Max Memory Support: 256 GB
Memory Speed: Up to 8400+
Memory Channels: Dual Channel
Memory Features: ECC & Non-ECC UDIMM, AMD EXPO™, AEMP, NitroPath DRAM
Expansion Slots:
PCIe 5.0 x16 (CPU)
PCIe 4.0 x16 (CPU / Chipset, varies by CPU)
Graphics Output:
HDMI
USB4 Type-C ×2
Wireless Connectivity:
WiFi 7
Bluetooth 5.4
Networking:
Realtek 5Gb Ethernet
Storage Support:
5 × M.2 Slots
4 × SATA 6Gb/s Ports
Back Panel I/O:
USB4 40Gbps Type-C ×2
USB 20Gbps Type-C (30W PD)
USB 10Gbps Type-A & Type-C
HDMI
Wi-Fi Module
5Gb Ethernet
Optical S/PDIF
Gold-Plated Audio Jacks
BIOS FlashBack
Clear CMOS Button
Internal Connectors:
24-pin ATX Power
2 × 8-pin CPU Power
CPU, AIO & Chassis Fan Headers
ARGB Gen 2 Headers
USB 20Gbps Type-C Header
USB 5Gbps & USB 2.0 Headers
Thermal Sensor Header
FlexKey Button
Start Button
Front Panel & Audio Headers
Warranty: 3 Years
