Specifications
Platform: Intel
Socket: LGA1851
CPU Support: Intel Core Ultra (Series 2)
Chipset: Z890
Memory
Supported Memory Type: DDR5
Max Memory Support: 256GB
Memory Speed: Up to 9066+
Channel Support: Dual Channel
Features: DIMM Fit, Intel XMP, ASUS AEMP III
Notes: Memory speed & module support depend on CPU & configuration
Graphics Output
1 × DisplayPort
1 × HDMI
1 × Thunderbolt 4 USB-C (DP Alt-Mode + Thunderbolt Video Output)
Expansion Slots
From CPU:
• 1 × PCIe 5.0 x16
From Chipset:
• 1 × PCIe 4.0 x16 (x4 mode)
• 1 × PCIe 4.0 x4
• 2 × PCIe 4.0 x1
Wireless Networking
Wi-Fi 7
Bluetooth 5.4
Back Panel I/O
1 × Thunderbolt 4 USB-C
1 × USB 20Gbps USB-C (DP Alt-Mode)
3 × USB 10Gbps Type-A
3 × USB 5Gbps Type-A
1 × DisplayPort
1 × HDMI
1 × Intel 2.5Gb Ethernet
1 × Wi-Fi Module
5 × Audio Jacks
1 × Optical S/PDIF Out
1 × BIOS FlashBack Button
Internal I/O Connectors
Cooling & Power
CPU Fan / CPU OPT / AIO Pump
4 × Chassis Fan Headers
1 × 24-Pin ATX Power
2 × 8-Pin CPU 12V Power
Storage
4 × M.2 (Key-M)
4 × SATA 6Gb/s
USB
1 × USB 20Gbps Front USB-C
1 × USB 5Gbps Header (2 Ports)
2 × USB 2.0 Headers (4 Ports)
Miscellaneous
3 × ARGB Gen 2 Headers
Clear CMOS Header
Chassis Intrusion Header
COM Port Header
Front Audio Header
Front Panel Header
Thunderbolt (USB4) Header
Form Factor: ATX
Warranty: 3 Years
