✅ Specifications
Platform: Intel
Chipset: Z890
Socket: LGA1851
CPU Support: Intel Core Ultra
Form Factor: ATX
Memory Type: DDR5
Memory Channels: Dual Channel
Max Memory Support: 256GB
Max Memory Speed: Up to 9200
Memory Features: ECC & Non-ECC Unbuffered, CUDIMM Support, Intel XMP
Graphics Output:
USB4 Type-C (DisplayPort)
DisplayPort
HDMI
Expansion Slots:
PCIe 5.0 x16 Slot (From CPU)
2 × PCIe 4.0 x16 Slots (x4 Mode, From Chipset)
Wireless Connectivity:
WiFi 7
Bluetooth 5.4
Back Panel I/O:
USB4 Type-C
USB 3.2 Gen2 Type-A
USB 3.2 Gen1 Ports
USB 2.0 Ports
DisplayPort
RJ-45 LAN
Optical S/PDIF Out
Audio Jacks
WiFi Antenna Connectors
Internal Connectors:
24-pin ATX Power Connector
2 × 8-pin CPU Power Connectors
CPU Fan Header
CPU/Water Pump Header
System Fan Headers
Addressable RGB Headers
RGB Header
4 × M.2 Slots
4 × SATA 6Gb/s Ports
USB Type-C Header
USB Headers
TPM Header
Power Button
Reset Button
Q-Flash Plus Button
Clear CMOS Jumper
Warranty: 3 Years
