✅ Specifications
Platform: AMD
Chipset: B650
Socket: AM5
CPU Support: Ryzen 7000, Ryzen 8000, Ryzen 9000 Series
Form Factor: ATX
Memory Type: DDR5
Memory Channels: Dual Channel
Max Memory Support: 256GB
Memory Speed Support: Up to 7200+ MT/s
Memory Features: AMD EXPO, Non-ECC Unbuffered
Graphics Output:
HDMI (x1)
DisplayPort (x1)
Expansion Slots:
PCIe 4.0 x16 (CPU)
PCIe 4.0 x4 (Chipset)
PCIe 3.0 x1 (Chipset)
Wireless Connectivity: WiFi 6E, Bluetooth 5.3
LAN: 2.5G Ethernet
Rear I/O Ports:
DisplayPort
HDMI
USB 3.2 Gen 2 Type-A (10Gbps)
USB 3.2 Gen 1 Type-A (5Gbps)
USB 3.2 Gen 2x2 Type-C (20Gbps)
Wi-Fi / Bluetooth
2.5G LAN
Audio Jacks
Flash BIOS Button
Internal Connectors:
24-pin ATX Power Connector
CPU Power Connectors
CPU Fan Header
Pump Fan Header
System Fan Headers
Front Panel Headers
Front Audio Header
COM Port Header
TPM Header (TPM 2.0)
RGB & ARGB Headers
USB 2.0 Headers
USB 5Gbps Headers
USB 10Gbps Type-C Header
Warranty: 3 Years
