✅ Specifications
Platform: AMD
Socket: AM5
Chipset: B840
CPU Support: Ryzen 7000, Ryzen 8000, Ryzen 9000 Series
Memory Type: DDR5
Max Memory Support: 256GB
Memory Speed: Up to 8000+ MHz
Memory Channels: Dual Channel
Memory Features: AMD EXPO™, JEDEC, Non-ECC Unbuffered, CUDIMM Support
Graphics Output:
HDMI 2.1
Expansion Slots:
PCIe 4.0 x16 (CPU)
PCIe 3.0 x4 (Chipset)
PCIe 3.0 x1 ×3 (Chipset)
Wireless Connectivity: WiFi 7, Bluetooth 5.4
LAN: 2.5G Ethernet
Back Panel I/O:
HDMI 2.1, USB 10Gbps Type-C, USB 10Gbps Type-A, USB 5Gbps Type-A, USB 2.0, LAN, Audio Jacks, WiFi/Bluetooth, Clear CMOS Button, Flash BIOS Button
Internal Connectors:
ATX Power, CPU Power, CPU & Pump Fan Headers, System Fan Headers, RGB & ARGB Headers, USB Headers, TPM 2.0 Header, COM Port, JDASH Connector, EZ Conn Header
Form Factor: ATX
Warranty: 3 Years
