✅ Specifications
Platform: AMD
Chipset: B850
Socket: AM5
CPU Support: Ryzen 7000, Ryzen 8000, Ryzen 9000 Series
Form Factor: ATX
Memory Type: DDR5
Memory Channels: Dual Channel
Max Memory Support: 256GB
Memory Speed Support: DDR5 8200–5600 (OC), 5600–4800 (JEDEC)
Memory Features: AMD EXPO, JEDEC, Non-ECC Unbuffered, CUDIMM
Graphics Output:
HDMI (x1)
DisplayPort 1.4 (x1)
Expansion Slots:
PCIe 4.0 x16 (CPU)
PCIe 4.0 x4 (Chipset)
PCIe 3.0 x1 (Chipset)
Wireless Connectivity: WiFi 6E, Bluetooth 5.3
LAN: 2.5G Ethernet
Rear I/O Ports:
Clear CMOS Button
DisplayPort 1.4
HDMI
USB 10Gbps Type-A
USB 10Gbps Type-C
USB 5Gbps Type-A
Wi-Fi / Bluetooth
2.5G LAN
HD Audio
Flash BIOS Button
Internal Connectors:
24-pin ATX Power Connector
CPU Power Connectors
CPU Fan Header
Pump / System Fan Header
System Fan Headers
Front Panel Headers
Front Audio Header
COM Port Header
TPM Header (TPM 2.0)
RGB & ARGB Headers
USB 2.0 Headers
USB 5Gbps Headers
USB 10Gbps Type-C Header
Warranty: 3 Years
