✅ Specifications
Platform: Intel
Chipset: B760
Socket: LGA1700
CPU Support: Intel 12th, 13th, 14th Gen, Pentium Gold, Celeron
Form Factor: Micro-ATX
Memory Type: DDR5
Memory Channels: Dual Channel
Max Memory Support: 256GB
Memory Speed Support: Up to 7800+ MT/s
Memory Features: Intel XMP, Non-ECC Unbuffered
Graphics Output:
HDMI 2.1
DisplayPort 1.4
Expansion Slots:
PCIe 5.0 x16 (CPU)
PCIe 3.0 x4 (Chipset)
Wireless Connectivity: WiFi 6E, Bluetooth 5.3
LAN: 2.5G Ethernet
Rear I/O Ports:
DisplayPort 1.4
HDMI 2.1
USB 3.2 Gen 2 Type-A (10Gbps)
USB 3.2 Gen 2x2 Type-C (20Gbps)
USB 2.0
Wi-Fi / Bluetooth
2.5G LAN
HD Audio
Internal Connectors:
24-pin ATX Power Connector
CPU Power Connectors
CPU Fan Header
Pump Fan Header
System Fan Headers
Front Panel Headers
Front Audio Header
TPM Header (TPM 2.0)
RGB & ARGB Headers
USB 2.0 Headers
USB 5Gbps Headers
USB 10Gbps Type-C Header
USB4 Add-on Card Header
Warranty: 3 Years
