✅ Specifications
Platform: AMD
Socket: AM5
Chipset: B650
CPU Support: Ryzen 7000, Ryzen 8000, Ryzen 9000 Series
Memory Type: DDR5
Max Memory Support: 128GB
Memory Speed: Up to 7200+ MHz
Memory Channels: Dual Channel
Memory Features: AMD EXPO™, Non-ECC Unbuffered
Graphics Output:
HDMI
DisplayPort
Expansion Slots:
PCIe 4.0 x16 (CPU)
PCIe 4.0 x4 (Chipset)
PCIe 3.0 x1 (Chipset)
Wireless Connectivity: WiFi 6E, Bluetooth 5.3
LAN: 2.5G Ethernet
Back Panel I/O:
HDMI, DisplayPort, USB 3.2 Gen2 Type-A, USB 3.2 Gen1 Type-A, USB Type-C 10Gbps, LAN, Audio Jacks, WiFi/Bluetooth, Flash BIOS Button
Internal Connectors:
ATX Power, Dual CPU Power, CPU & Pump Fan Headers, System Fan Headers, RGB & ARGB Headers, USB Headers, TPM 2.0 Header, COM Port, JDASH Connector
Form Factor: Micro-ATX
Warranty: 3 Years
