✅ Specifications
Platform: Intel
Chipset: B860
Socket: LGA1851
CPU Support: Intel Core Ultra
Form Factor: Micro-ATX
Memory Type: DDR5
Memory Channels: Dual Channel
Max Memory Support: 256GB
Memory Speed Support: Up to 8800+ MT/s
Memory Features: Intel XMP 3.0, JEDEC, Non-ECC Unbuffered, CUDIMM
Graphics Output:
HDMI
DisplayPort
USB-C DisplayPort
Expansion Slots:
PCIe 5.0 x16 (CPU)
PCIe 4.0 x1 (x2 from chipset)
PCIe 4.0 x4 (chipset)
Wireless Connectivity: WiFi 7, Bluetooth 5.4
LAN: 5G Ethernet
Rear I/O Ports:
DisplayPort
HDMI
Thunderbolt 4 Type-C (40Gbps)
USB 10Gbps Type-A
USB 5Gbps Type-A
USB 5Gbps Type-C
USB 2.0
Keyboard / Mouse Port
Wi-Fi / Bluetooth
5G LAN
Audio Jacks
Clear CMOS Button
Internal Connectors:
ATX Power Connector
CPU Power Connectors
PCIe 8-pin Power Connector
CPU Fan Header
Pump / System Fan Header
System Fan Headers
Front Panel Headers
Front Audio Header
COM Port Header
TPM Header (TPM 2.0)
RGB & ARGB Headers
USB 2.0 Headers
USB 5Gbps Headers
USB 10Gbps Type-C Header
Thunderbolt 5 Add-on Card Header
Warranty: 3 Years
