✅ Specifications
Platform: Intel
Chipset: Z790
Socket: LGA1700
CPU Support: 14th Gen / 13th Gen / 12th Gen Intel Core, Pentium Gold, Celeron
Form Factor: ATX
Memory Type: DDR5
Memory Channels: Dual Channel
Max Memory Support: 256GB
Max Memory Speed: Up to 7200+
Memory Features: Intel XMP 3.0, Non-ECC Unbuffered
Graphics Output:
HDMI 2.1
DisplayPort
Expansion Slots:
1 × PCIe 5.0 x16 (CPU)
1 × PCIe 4.0 x4 (Chipset)
2 × PCIe 3.0 x1 (Chipset)
Wireless Connectivity:
Intel WiFi 6E
Bluetooth 5.3
LAN: 2.5G Ethernet
Back Panel I/O:
USB 3.2 Gen 2x2 Type-C (20Gbps)
USB 3.2 Gen 2 Type-A (10Gbps)
USB 3.2 Gen 1 Type-A (5Gbps)
USB 2.0
HDMI
DisplayPort
PS/2 Keyboard / Mouse
WiFi Antenna
Flash BIOS Button
Audio Jacks
Internal Connectors:
24-pin ATX Power Connector
Dual CPU Power Connectors
CPU Fan Header
Pump Fan Header
6 × System Fan Headers
RGB & ARGB Headers
USB 2.0 Headers
USB 5Gbps Headers
USB 10Gbps Type-C Header
USB4 Add-in Card Header
Front Panel & Audio Headers
TPM 2.0 Header
Warranty: 3 Years
