Specifications
Part Number: CL-W322-PL12GM-B
Pump
Motor Speed: 3200 RPM
Rated Voltage: 12V
Rated Current: 0.38A
Power Input: 4.56W
CPU LCD Display
Display Type: 2.1″ TFT-LCD (IPS)
Resolution: 480 × 480 px (RGB)
Rated Voltage: 5V
Power Input: 11.5W
Interface: Micro-USB to USB (9-Pin)
System Compatibility: Windows 7 / 8 / 8.1 / 10
Water Block
Material: Copper
Fans (120mm)
Dimensions: 120 × 120 × 25 mm
Speed: PWM 500 – 2500 RPM (4-Pin)
Noise Level: 28.1 dBA
Power Input: 2.76W (per fan)
Rated Voltage: 12V
Rated Current: 0.23A (per fan)
Max Airflow: 72.69 CFM (per fan)
Max Static Pressure: 3.78 mm-H₂O (per fan)
Tubing
Length: 400 mm
Material: Rubber
Radiator
Dimensions: 273 × 120 × 27 mm
Material: Aluminum
CPU Socket Compatibility
Intel: LGA 2066 / 2011-3 / 2011 / 1700 / 1200 / 1156 / 1155 / 1151 / 1150
AMD: AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2 / FM1
Warranty
2 Years
