✅ Specifications
Platform: AMD
Socket: AM5
Chipset: B650
CPU Support: Ryzen 7000, Ryzen 8000, Ryzen 9000 Series
Memory Type: DDR5
Max Memory Support: 256GB
Memory Speed: Up to 7600 MHz
Memory Channels: Dual Channel
Memory Features: AMD EXPO™, XMP, Non-ECC Unbuffered DIMM
Graphics Output:
2 × DisplayPort
1 × HDMI
Expansion Slots:
PCIe x16 (PCIe 4.0 – CPU dependent)
PCIe x1 (PCIe 3.0 – Chipset)
Wireless Connectivity: WiFi 6E, Bluetooth 5.3
LAN: RJ-45 Ethernet
Storage Support:
2 × M.2 NVMe Slots
4 × SATA 6Gb/s Ports
Back Panel I/O: USB Type-C, USB 3.2 Gen 1, USB 2.0, HDMI, DisplayPort, Audio Jacks, LAN, PS/2
Internal Connectors: ATX Power, CPU Power, Fan Headers, RGB & ARGB Headers, USB Headers, TPM Header, Q-Flash Plus
Form Factor: Micro-ATX
Warranty: 3 Years
