✅ Specifications
Platform: AMD
Socket: AM5
Chipset: B850
CPU Support: Ryzen 7000, Ryzen 8000, Ryzen 9000 Series
Memory Type: DDR5
Max Memory Support: 256GB
Memory Speed: Up to 8200+ MHz
Memory Channels: Dual Channel
Memory Features: AMD EXPO™, JEDEC, Non-ECC Unbuffered, CUDIMM Support
Graphics Output:
HDMI
DisplayPort
Expansion Slots:
PCIe 5.0 x16 (CPU)
PCIe 3.0 x1 (Chipset) ×3
Networking: 5G LAN
Back Panel I/O:
HDMI, DisplayPort, USB 10Gbps Type-C, USB 10Gbps Type-A, USB 5Gbps Type-A, USB 2.0, Audio Jacks, Clear CMOS Button, Flash BIOS Button
Internal Connectors:
ATX Power, CPU Power, PCIe Power (8-pin), CPU Fan, System Fans, Pump Header, RGB & ARGB Headers, USB Headers, TPM 2.0 Header, COM Port, JDASH Connector
Form Factor: Micro-ATX
Warranty: 3 Years
